20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

Dongguan Nan Bo Mechanical Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

  • 1
  • 2
  • 3
  • 4

Brand Name : Nanbo

Model Number : ZDFM-540

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10,000 pcs per Month

Delivery Time : About 25 days

Packaging Details : wooden packing

Name : Automatic Laminating Machine

Max Laminating width : 540mm

Max Laminating Thickness : 2mm

Max Laminating speed : 0-20M/min

Max Laminating Temperature : 130℃

Electricity Supply : 220v / 50Hz, 6kw

Motor Power : AC 6kw

Diameter of steel Roller : 200mm

Robber roller diameter : 150mm

Heating method : Infrared internal heating

Heating power : 6000w

Advantage : Durable quality laminating machine

Factory : Nanbo machinery

Contact Now

Automatic Air Pressure Laminating Machine

Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

ZDFM-540 Automatic laminating machine is a pre-coate compounding equipment meticulously rearched and developed by our company according to the market demand.this machine possesses the features of compact structure ,small area occupancy and convenient operation

ZDFM-540 Laminating Machine Specifications

Model ZDFM-540
Max laminating width 540mm
Max laminating thickness 2mm
Laminating speed 0-20M/Min
Max. heating temperature 130
Display screen Touch screen
Steel roller diameter 200mm
Robber roller diameter 150mm
Heating method Infrared internal heating
Heating power 6KW
Motor Power 400W
Anti-curling function YES
Auto overlap function NO
Auto pull-off function YES
Power supply 220V/50HZ
Machine size

2300*960*1400mm

Net weight/gross weight 600KG

Main Feature:

1:Adopt the pneumatic pressure compound

2:Adopt the automatic paper feeding mechanism and realize once finishing feeding ,laminating and slitting

3:The paper feeding mechanism is the pre-paper feeding structure,servo motor drive

4:The edge lapping adopts the back-paper press pre-paper mode,while operating,only input the sheets length,the edge lapping length can achieve the automatic laminating,the edge lapping length prcision can reach up±2mm

5:The cylinder uses the guide heating oil to heat,surface temperature measurement,accurate and uniform temperature

6:Equipment with the thin paper anti-curl device,so as to ensure the thin paper compounding no crimp

7:Equipment with the front and back way holing device,which can prevent the paper breaks after cutting or before cutting while holing on the way film so as to realize the more stable operation

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

20M/min 6kw Automatic Roll Laminating Machines 540*700 Mm Max Lamination Width Air Pressure

Can this hydraulic automatic laminating machine be used in school?

Yes, no problem. It is not too big, so it can be used at school.

Do you have an available video about this laminating machine?

Of course, we have. We can show you the video.

What's the max laminating width?

It is 635mm.

Which other laminating machines do you have in your factory?

We have various laminators, such as 330LED, DSG-520YA, DSG-390, DSG-520Z.ZDFM-540 DSG-720Z

Can you show me pictures of the laminators before shipping?

Yes, of course. No problem.

What's the price of this laminating machine?

We will offer you with factory price. It is more favorable when your order quantity is larger.

Can I ask for repair service if the machine doesn't work?

Normally, we do careful goods inspection of the machine before shipping. Meanwhile, we provide prompt after-sale service after you purchase the goods from our factory.

Will you offer me a discount price if I purchase many pcs?

Yes, we will. Price is more favorable when your order quantity is big.

Is it possible to ship this FM-650 roller laminator to my agent in Guangzhou?

Yes, we would love to cooperate. For the shipping, we can ship to your agent or directly to you. It depends on your requirement.

►About Our Service:

If you have an interest in this laminating machine, contact us directly.


If you are looking for other models or you just want other equipment to meet your special requirement, please let us know. Then we will help find out a solution.


After you order this book laminator machine and don't know how to use it. We will provide a video to show you how to operate it. If your machine doesn't work when receiving, just tell us the situation, and our professional masters will help you solve it.

Customers always come first in our company. Hope to establish a solid business relationship with you! Contact me now.

What we can do?


We will recommend the most suitable goods based on your specifications. Then competitive prices can be offered.
We will prepare the goods you ordered within 15-20 days. Then ship the goods to your destination.

After you order the roller laminating machine and the production finishes, we will arrange the shipping for you.
Shipping channels you can choose are DHL, FedEx, UPS, TNT or Ocean shipping, etc.
The packing we used, they are normally solid carton boxes or wooden boxes. We will ensure that your goods will be protected very well.

►What we supply:

After-printing book equipment: Double loop wire forming machine, double loop wire binding machine, semi-automatic punching machine, automatic punching machine, double loop wire binding &paper punching machine, single-loop forming spiral & binding machine, plastic spiral coil forming machine, plastic spiral coil binding machine, calendar hanger forming machine, book sewing machine, book folding machine.
Mylar tab lamination machine, glue perfect binding machine, saddle stitching machine, Roll Laminating Machine etc.

Binding material: plastic spiral coil, double loop wire, nylon coated wire, Metal Spiral coil. PVC filament, PVC Binding Cover, Calendar Hanger Plastic Binding Comb, Plastic Binding Slider, Plastic Binding Press, Stitching Wire, etc.

Welcome to choose the items you need and look forward to establishing a long-term business relationship with you and your company!

► The fairs we attend are like Canton Fair, the International Printing Technology Exhibition of China(Guangdong), etc. Look forward to seeing you there.
